Silicon Graphics GDM-5411 User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5411
7-3
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
(a)
R130 1-216-113-00 RES,CHIP 470K 5% 1/10W
R137 1-249-413-11 CARBON 470 5% 1/4W
R138 1-216-017-91 RES,CHIP 47 5% 1/10W
R161 1-216-041-00 RES,CHIP 470 5% 1/10W
R201 1-215-394-00 METAL 75 1% 1/4W
R202 1-216-097-91 RES,CHIP 100K 5% 1/10W
R203 1-215-394-00 METAL 75 1% 1/4W
R205 1-216-017-91 RES,CHIP 47 5% 1/10W
R206 1-216-017-91 RES,CHIP 47 5% 1/10W
R207 1-216-045-00 RES,CHIP 680 5% 1/10W
R209 1-216-075-00 RES,CHIP 12K 5% 1/10W
R210 1-216-097-91 RES,CHIP 100K 5% 1/10W
R211 1-216-033-00 RES,CHIP 220 5% 1/10W
R212 1-216-009-91 RES,CHIP 22 5% 1/10W
R213 1-216-017-91 RES,CHIP 47 5% 1/10W
R214 1-216-009-91 RES,CHIP 22 5% 1/10W
R215 1-219-742-11 CARBON 47 5% 1/2W
R216 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R217 1-216-121-91 RES,CHIP 1M 5% 1/10W
R218 1-216-121-91 RES,CHIP 1M 5% 1/10W
R219 1-216-077-91 RES,CHIP 15K 5% 1/10W
R220 1-216-113-00 RES,CHIP 470K 5% 1/10W
R221 1-216-113-00 RES,CHIP 470K 5% 1/10W
R222 1-216-081-00 RES,CHIP 22K 5% 1/10W
R228 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R230 1-216-113-00 RES,CHIP 470K 5% 1/10W
R237 1-249-413-11 CARBON 470 5% 1/4W
R238 1-216-017-91 RES,CHIP 47 5% 1/10W
R261 1-216-041-00 RES,CHIP 470 5% 1/10W
R301 1-215-394-00 METAL 75 1% 1/4W
R303 1-215-394-00 METAL 75 1% 1/4W
R305 1-216-017-91 RES,CHIP 47 5% 1/10W
R306 1-216-017-91 RES,CHIP 47 5% 1/10W
R307 1-216-045-00 RES,CHIP 680 5% 1/10W
R309 1-216-075-00 RES,CHIP 12K 5% 1/10W
R310 1-216-097-91 RES,CHIP 100K 5% 1/10W
R311 1-216-033-00 RES,CHIP 220 5% 1/10W
R312 1-216-009-91 RES,CHIP 22 5% 1/10W
R313 1-216-017-91 RES,CHIP 47 5% 1/10W
R314 1-216-009-91 RES,CHIP 22 5% 1/10W
R315 1-219-742-11 CARBON 47 5% 1/2W
R316 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R317 1-216-121-91 RES,CHIP 1M 5% 1/10W
R318 1-216-121-91 RES,CHIP 1M 5% 1/10W
R319 1-216-077-91 RES,CHIP 15K 5% 1/10W
R320 1-216-113-00 RES,CHIP 470K 5% 1/10W
R321 1-216-113-00 RES,CHIP 470K 5% 1/10W
R322 1-216-081-00 RES,CHIP 22K 5% 1/10W
R328 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R330 1-216-113-00 RES,CHIP 470K 5% 1/10W
R337 1-249-413-11 CARBON 470 5% 1/4W
R338 1-216-017-91 RES,CHIP 47 5% 1/10W
R361 1-216-041-00 RES,CHIP 470 5% 1/10W
R402 1-216-049-91 RES,CHIP 1K 5% 1/10W
R403 1-216-081-00 RES,CHIP 22K 5% 1/10W
R404 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R405 1-216-045-00 RES,CHIP 680 5% 1/10W
R406 1-216-097-91 RES,CHIP 100K 5% 1/10W
R407 1-218-768-11 METAL CHIP 470K 0.50%1/10W
R409 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R411 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R412 1-216-105-91 RES,CHIP 220K 5% 1/10W
R413 1-216-097-91 RES,CHIP 100K 5% 1/10W
R414 1-216-089-91 RES,CHIP 47K 5% 1/10W
R415 1-216-097-91 RES,CHIP 100K 5% 1/10W
R417 1-216-121-91 RES,CHIP 1M 5% 1/10W
R418 1-260-127-11 CARBON 220K 5% 1/2W
R419 1-216-033-00 RES,CHIP 220 5% 1/10W
R420 1-216-025-91 RES,CHIP 100 5% 1/10W
R421 1-216-025-91 RES,CHIP 100 5% 1/10W
R422 1-216-025-91 RES,CHIP 100 5% 1/10W
R424 1-216-049-91 RES,CHIP 1K 5% 1/10W
R425 1-216-049-91 RES,CHIP 1K 5% 1/10W
R426 1-216-105-91 RES,CHIP 220K 5% 1/10W
R427 1-216-049-91 RES,CHIP 1K 5% 1/10W
R428 1-216-025-91 RES,CHIP 100 5% 1/10W
R430 1-216-025-91 RES,CHIP 100 5% 1/10W
R431 1-216-113-00 RES,CHIP 470K 5% 1/10W
R436 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R438 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R439 1-216-041-00 RES,CHIP 470 5% 1/10W
R441 1-216-121-91 RES,CHIP 1M 5% 1/10W
R442 1-216-049-91 RES,CHIP 1K 5% 1/10W
R443 1-216-025-91 RES,CHIP 100 5% 1/10W
R444 1-216-025-91 RES,CHIP 100 5% 1/10W
R445 1-216-025-91 RES,CHIP 100 5% 1/10W
R446 1-216-025-91 RES,CHIP 100 5% 1/10W
R447 1-216-017-91 RES,CHIP 47 5% 1/10W
R448 1-216-017-91 RES,CHIP 47 5% 1/10W
R449 1-216-081-00 RES,CHIP 22K 5% 1/10W
R450 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R451 1-216-115-00 RES,CHIP 560K 5% 1/10W
R453 1-216-073-00 RES,CHIP 10K 5% 1/10W
R454 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R455 1-216-097-91 RES,CHIP 100K 5% 1/10W
R456 1-216-025-91 RES,CHIP 100 5% 1/10W
R457 1-211-895-11 METAL 10M 10% 1/4W
R458 1-219-398-51 METAL 2.2M 5% 1W
R459 1-211-895-11 METAL 10M 10% 1/4W
R460 1-216-073-00 RES,CHIP 10K 5% 1/10W
R461 1-216-105-91 RES,CHIP 220K 5% 1/10W
R463 1-216-097-91 RES,CHIP 100K 5% 1/10W
R464 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R488 1-216-089-91 RES,CHIP 47K 5% 1/10W
R490 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R491 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
<SPARK GAP>
SG101 1-576-354-21 GAP, SPARK
SG201 1-576-354-21 GAP, SPARK
