Silicon Graphics GDM-5411 User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5411
7-7
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
(d)
C535 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C536 1-126-967-11 ELECT 47µF 20% 50V
C537 1-113-694-11 FILM 0.056µF 5% 400V
C538 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C539 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C540 1-106-343-00 MYLAR 0.001µF 10% 200V
C541 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C542 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C543 1-135-350-11 FILM 3600pF 3% 1.8KV
C544 1-125-925-11 FILM MELF 0.027µF 5% 400V
C545 1-107-597-11 CERAMIC 22pF 5% 500V
C546 1-107-444-11 CERAMIC 100pF 5% 2KV
C547 1-130-061-91 FILM 0.0015µF 5% 630V
C548 1-162-134-11 CERAMIC 470pF 10% 2KV
C549 1-130-495-00 FILM 0.1µF 5% 50V
C550 1-127-833-11 FILM 0.15µF 5% 400V
C551 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C552 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C554 1-107-444-11 CERAMIC 100pF 5% 2KV
C555 1-107-683-11 ELECT 2.2µF 0 250V
C556 1-115-356-11 FILM 1.2µF 5% 250V
C557 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C558 1-104-665-11 ELECT 100µF 20% 25V
C559 1-107-649-11 ELECT 2.2µF 20% 250V
C560 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C561 1-104-664-11 ELECT 47µF 20% 25V
C562 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C563 1-163-011-11 CERAMIC CHIP 0.0015µF 10% 50V
C564 1-126-960-11 ELECT 1µF 20% 50V
C565 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C566 1-137-370-11 FILM 0.01µF 5% 50V
C567 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C568 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C571 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C572 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C573 1-106-375-12 MYLAR 0.022µF 200V
C574 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C575 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C577 1-126-964-11 ELECT 10µF 20% 50V
C701 1-128-560-11 ELECT 22µF 20% 100V
C702 1-128-562-11 ELECT 47µF 20% 100V
C703 1-104-331-11 CERAMIC 0.0022µF 10% 1KV
C704 1-104-568-11 CERAMIC 470pF 10% 2KV
C706 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C707 1-130-495-00 FILM 0.1µF 5% 50V
C708 1-126-942-61 ELECT 1000µF 20% 25V
C709 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C710 1-107-894-11 ELECT 220µF 20% 35V
C711 1-163-019-00 CERAMIC CHIP 0.0068µF 10% 50V
C712 1-106-228-00 MYLAR 0.22µF 10% 100V
C713 1-126-942-61 ELECT 1000µF 20% 25V
C715 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C720 1-126-964-11 ELECT 10µF 20% 50V
C901 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C902 1-104-665-11 ELECT 100µF 20% 25V
C903 1-126-964-11 ELECT 10µF 20% 50V
C905 1-163-127-00 CERAMIC CHIP 270pF 5% 50V
C907 1-163-257-11 CERAMIC CHIP 180pF 5% 50V
C908 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C909 1-126-935-11 ELECT 470µF 20% 16V
C910 1-126-962-11 ELECT 3.3µF 20% 50V
C912 1-106-383-00 MYLAR 0.047µF 10% 200V
C913 1-119-748-11 ELECT 33µF 20% 400V
C914 1-106-383-00 MYLAR 0.047µF 10% 200V
C915 1-136-169-00 FILM 0.22µF 5% 50V
C916 1-117-626-11 FILM 2000pF 3% 1.2KV
C917 1-117-665-11 FILM 0.33µF 5% 250V
C918 1-106-359-00 MYLAR 0.0047µF 10% 100V
C919 1-115-350-51 CERAMIC 0.0047µF 2KV
C920 1-137-372-11 FILM 0.022µF 5% 50V
C921 1-106-228-00 MYLAR 0.22µF 10% 100V
C922 1-106-220-00 MYLAR 0.1µF 10% 100V
C923 1-106-355-12 MYLAR 0.0033µF 10% 200V
C924 1-106-220-00 MYLAR 0.1µF 10% 100V
C925 1-126-967-11 ELECT 47µF 20% 50V
C926 1-126-964-11 ELECT 10µF 20% 50V
C927 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C928 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C929 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C930 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C931 1-126-964-11 ELECT 10µF 20% 50V
C932 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C933 1-126-960-11 ELECT 1µF 20% 50V
C935 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
<CONNECTOR>
CN501*1-564-509-11 PLUG, CONNECTOR 6P
CN502*1-564-510-11 PLUG, CONNECTOR 7P
CN503*1-508-879-11 BASE POST
CN504 1-784-786-11 CONNECTOR, FFC 25P
CN505 1-784-786-11 CONNECTOR, FFC 25P
CN506 1-764-101-11 PIN, CONNECTOR (PC BOARD) 2P
CN508*1-564-511-11 PLUG, CONNECTOR 8P
CN509*1-778-955-11 PIN, CONNECTOR (PC BOARD) 10P
<DIODE>
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-110-36 ZENER DIODE RD13ESB2
D506 8-719-991-33 DIODE 1SS133T-77
D507 8-719-063-89 DIODE YG911S3R
D508 8-719-031-79 DIODE D5SC4M
D509 8-719-991-33 DIODE 1SS133T-77
D510 8-719-109-85 ZENER DIODE RD5.1ESB2
D511 8-719-066-36 DIODE FMQ-G5GS
D512 8-719-988-61 DIODE 1SS355TE-17
D513 8-719-991-33 DIODE 1SS133T-77
D514 8-719-991-33 DIODE 1SS133T-77
D515 8-719-109-89 ZENER DIODE RD5.6ESB2
D516 8-719-991-33 DIODE 1SS133T-77
D517 8-719-951-30 DIODE ERA91-02
D519 8-719-988-61 DIODE 1SS355TE-17
