Operation Manual S15
Page
42
12. Technical Specifications
Power supply DC 12 V +30/-10%
Channel capability 57 international channels
UK: includes M1 (previously 37) and M2
Frequency Resolution 25KHz
Method of frequency generation synthesizer
Dimension 175(W) × 79(H) ×130(D) mm
Weight 1175 grams
12.1 RECEIVER
Multi Channel Receiver
1. The receiver incorporates a dual conversion super-heterodyne design.
2. Tuning frequency range 156.025-163.275MHz
3. IF frequency used: 21.4MHz; 455KHz
4. Maximum useable sensitivity ≤6dBµe.m.f. of 20dB/SINAD
5. Adjacent Channel selectivity ≥70dB
6. Spurious Response Rejection ≥70dB
7. Inter-modulation Rejection ≥68dB
8. Spurious Emission radiation 2nW
9. Current: 0.9 Amps (Max Audio)
0.3 Amps (STBY)
10. Audio Frequency Response +1, -3dB of +6dB/octave
De-emphasis 300-3000Hz
11. Hum and Noise ≤40dB
12. Audio output 3.5W at less than 10% distortion
with 8 Ohm external speaker
2W only internal speaker
