Silva s15 User Manual

Operation Manual S15
Page
8
ENTER KEY (ENT)
Confirms the action.
CLEAR KEY (CLR)
Stop tasks and returns to main screen or returns to the last screen.
◄ / ► Key
Moves the cursor position when setting.
▲/ ▼ KEY
Use to select working channel (Up or Down). Can also be used to select
stored working channels. Allows viewing of next or previous message
and selection next or previous item.
PTT BUTTON
Keys the transmitter allowing you to transmit a message.
(CALL) KEY.
Activates ‘CALL’ menu.

Silva s15 Specifications

General

Receiver Sensitivity	0.25 μV (12dB SINAD)
Channel Spacing	25 kHz
Modulation	FM
Current Consumption	1.5A (max)
Frequency Range	400-470MHz
Output Power	5W
