Specifications
56
Receiver
Output impedance 600 ohms
THD >60 dB (1 kHz)
Crosstalk <- 65 dB
Initial volume Saves last volume set
video parameters,
output:
Output level FBAS 1 Vss, 75 ohms
Output level RED 0.7 Vss, 75 ohms
Output level GREEN 0.7 Vss, 75 ohms
Output level BLUE 0.7 Vss, 75 ohms
Teletext:
Teletext filter According to ETS 300 472 standard
Reception of Teletext data (FBAS) according to ITU-R BT.653-
2, lines: 6-22 and 320-335
Connection options
TV SCART (output) CVBS/FBAS and RGB,
Audio L, R , YUV
VCR SCART (output and
input)
CVBS/FBAS, Audio L, R
RCA Audio L,R
COAXIAL Digital audio output
Antenna IN VHF/UHF, 5V/100mA
Antenna OUT VHF/UHF
RS232 9pin D-Sub, bidirectional, 115 kBit/s
