CRYSTALCUBE—User Manual
Views of Projector Parts
Front-right View
ITEM LABEL DESCRIPTION SEE PAGE
1.
IR receiver Receive IR signal from remote control
2.
Lens Projection Lens
3.
Focus ring Focuses the projected image
4.
Zoom ring Enlarges the projected image
17
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
— 2 —
