SimCom SIM7020C Hardware Design

Smart Machine Smart Decision
SIM7020_Hardware_Design_V1.02 29 2018-07-25
4 RF Specifications
4.1 LTE RF Specifications
Table 18: Conducted transmission power
Frequency
Power
Min.
LT E -FDD B1
23dBm +/-2.7dB
<-40dBm
LT E -FDD B2
23dBm +/-2.7dB
<-40dBm
LT E -FDD B3
23dBm +/-2.7dB
<-40dBm
LT E -FDD B4
23dBm +/-2.7dB
<-40dBm
LT E -FDD B5
23dBm +/-2.7dB
<-40dBm
LT E -FDD B6
23dBm +/-2.7dB
<-40dBm
LT E -FDD B8
23dBm +/-2.7dB
<-40dBm
LT E -FDD B12
23dBm +/-2.7dB
<-40dBm
LT E -FDD B13
23dBm +/-2.7dB
<-40dBm
LT E -FDD B18
23dBm +/-2.7dB
<-40dBm
LT E -FDD B19
23dBm +/-2.7dB
<-40dBm
LT E -FDD B20
23dBm +/-2.7dB
<-40dBm
LT E -FDD B26
23dBm +/-2.7dB
<-40dBm
LT E -FDD B28
23dBm +/-2.7dB
<-40dBm
LT E -FDD B39
23dBm +/-2.7dB
<-40dBm
*Note
：
The max power is tested result single-tone in CAT-NB1. Multi-tone test results please
refer to part 6.2.3F.3 for CAT-NB1.
Table19: Maximum Power Reduction (MPR) for UE category NB1 Power Class 3
Modulation
QPSK
Tone positions for 3
Tones allocation
0-2 3-5 and 6-8 9-11
MPR
≤ 0.5 dB
0 dB
≤ 0.5 dB
Tone positions for 6
Tones allocation
0-5 and 6-11
MPR
≤ 1 dB
≤ 1 dB
Tone positions for 12
Tones allocation
0-11
MPR
≤ 2 dB
Table 20: E-UTRA operating bands
E-UTRA UL Freq. DL Freq. Duplex Mode
1
1920 ~1980 MHz
2110 ~2170 MHz
HD-FDD
