SimCom SIM7020C Hardware Design

Smart Machine Smart Decision
SIM7020_Hardware_Design_V1.02 38 2018-07-25
eDRX mode supply current
（Tested i n sl eep mode）
@PTW=10.24s, eDRX=20.48s, DRX=1.28s
Typical：230uA
@PTW=10.24s, eDRX=20.48s, DRX=2.56s
Typical
：130uA
@PTW=20.48s, eDRX=81.92s, DRX=2.56s
Typical：95uA
@PTW=20.48s, eDRX=162.84s, DRX=2.56s
Typical：77.5uA
@PTW=40.96s, eDRX=655.36s, DRX=2.56s
Typical：69uA
LTE data
LT E -FDD B1
@23dbm Typical: 134mA
@10dbm Typical: 42mA
@0dbm Typical: 32mA
LT E -FDD B3
@23dbm Typical: 116mA
@10dbm Typical: 44mA
@0dbm Typical: 31 mA
LT E -FDD B5
@23dbm Typical: 116mA
@10dbm Typical: 35mA
@0dbm Typical: 25mA
LT E -FDD B8
@23dbm Typical: 128mA
@10dbm Typical: 35mA
@0dbm Typical: 25mA
LT E -FDD B20
@23dbm Typical: 113mA
@10dbm Typical: 34mA
@0dbm Typical: 26mA
LT E -FDD B28
@23dbm Typical: 126mA
@10dbm Typical: 38mA
@0dbm Typical: 27mA
5.5 ESD Notes
SIM7020 is sensitive to ESD in the process of storage, transporting, and assembling. When SIM7020
is mounted on the users’ mother board, the ESD components should be placed beside the connectors
which human body may touch, such as SIM card holder, audio jacks, switches, keys, etc. The
following table shows the SIM7020 ESD measurement performance without any external ESD
component.
Table 31: The ESD performance measurement table
Part
Contact discharge(kV)
Air discharge(kV)
GND （Shield）
+/-6
+/-12
GND （RF）
+/-6
+/-12
VB AT
+/-5
+/-10
Antenna port
+/-5
+/-10
Other PADs
+/-3
+/-6
Note: Temperature: 25
℃
, Humidity: 45%, tested on SIMCOM-EVB.
