Sime HOME PLUS - Menu Navigation Tree

18
EN
clic
k
To “select” rows or “modify” values
To
“confirm” the selections or modifications
ZONE HEATING
Room set 20.0°C
Heating set 0°C
Heating temp. 28.0°C
BOILER
Return temperature 25.0°C
Power output 0%
System pressure 1.2bar
Exhaust temp. _ _ _°C
HOT WATER
Hot water temp 51.2C
Hot water set 50°C
Flow rate --l/min
MENU
GENERAL SETTINGS [...]
INFORMATION [...]
TECHNICAL [...]
4.2.4 MENU button for navigation tree
Modo: Inverno Progr. automatico - Set 18,0 Cfino alle 11:30
Menu Modo
VISUALIZATION
Contrast 10
Lighting display 34
Lighting knob ON
MENU
ZONE HOT WATER
Enable anti-legionella function NO
Enable anti-legionella function Mo
Time of the intervention 02:00
TECHNICAL
Zone heating [...]
Hot water [...]
Boiler parameters [...]
Reset alarm history [...]
Factory total reset [...]
Customer service [...]
(section 4.2.1 on page 10)
(section 4.2.2 on page 13)
(section 4.2.3 on page 14)
MENÙ
IMPOSTAZIONI GENERALI [...]
INFORMAZIONI [...]
TECNICO [...]
(Queste videate sono di sola visualizzazione. NON è possibile effettuare la modifica dei dati)
CONFIRM REQUEST
a
Confirm operation?
[CONFIRM]
TECHNICAL
ZONE HEATING
Room probe run YES
Room probe modul. YES
Ext. probe modul. YES
Weather comp.curve 3.0
Weather comp. offset 0°C
Backlash off temp. 0.1°C
System inertia 10
Flow temp.min. set 20°C
Antifreeze enable YES
Antifreeze set 5.0°C
Room probe offset 0.0°C
INFORMATION
Zone heating [...]
Boiler [...]
Hot water [...]
Alarms [...]
Firmware version 100
GENERAL SETTINGS
Language [...]
Date and time [...]
Visualization [...]
Factory settings [...]
