General Information 4
DESCRIPTION
These submersible pumps are designed for use as a utility
pump. The units are equipped with a 3-prong grounding-
type power cord. Ball bearings on the motor shaft never
need lubrication. Automatic reset thermal protection.
SPECIFICATIONS
Power supply required..................................115V, 60 HZ.
Motor duty.......................................................intermittent
Liquid Temp. Range .......................32°F to 77°F (0°-25°C)
Individual Branch Circuit
Requirement (minimum) ......................................15 Amps
NOTICE: Not designed for applications involving salt
water or brine! Use with salt water or brine will void
warranty.
NOTICE: Not for use in water where fish are present.
For parts or assistance, call Simer Customer Service at 1-800-468-7867 / 1-800-546-7867
GPH (LPH) AT TOTAL FEET (M) No Flow
Motor 1 5 10 15 20 25 At Height
Model HP (.3 M) (1.5 M) (3 M) (4.6 M) (6.1 M) (7.6 M) Shown Below
2325 1/4 1,200 (4,542) 1,000 (3,785) 675 (2,555) 400 (1,514) – – 20’ (6.1 M)
2360 1/3 2,300 (8,706) 1,975 (7,476) 1,425 (5,394) 850 (3,218) 300 (1,136) – 22’ (6.7 M)
2385 1/2 3,000 (11,356) 2,500 (9,464) 1,900 (7,192) 1,320 (4,997) 750 (2,839) – 25’ (7.6 M)
PERFORMANCE
Motor Minimum Pumps
Motor Full Load Circuit Down
Model H.P. Amps Req. (Amps) To
2325 1/4 1.5 15 7/16” (11mm)
2360 1/3 2.6 15 7/16” (11mm)
2385 1/2 3.0 15 7/16” (11mm)
Pump
Model No. Included Adapters
2325 1-1/4” FBSP X 1” FNPT
1” MNPT X 3/4” M Garden Hose
2360 1-1/4” FBSP X 1” FNPT
1” MNPT X 3/4” M Garden Hose
2385 1-1/4” FBSP X 1” FNPT
1” MNPT X 3/4” M Garden Hose
1-1/4” FBSP X 1-1/4” & 1” Hose Barb
DISCHARGE FITTINGS CHART
ELECTRICAL SPECIFICATIONS
