For parts or assistance, call Simer Customer Service at 800-468-7867
Operation
Risk of electric shock. Can shock,
burn or kill. Do not handle a pump or pump
motor with wet hands or when standing on wet
or damp surface, or in water.
1. Shaft seal depends on water for lubrication.
Do not operate pump unless it is submerged
in water as seal may be damaged if allowed
to run dry.
2. Motor is equipped with automatic reset
thermal protector. If temperature in motor
should rise unduly, switch will cut off all
power before damage can be done to motor.
When motor has cooled sufficiently, switch
will reset automatically and restart motor.
If protector trips repeatedly, pump should
be removed and checked as to cause of
difficulty. Low voltage, long extension cords,
clogged impeller, very low head or lift, or a
plugged or frozen discharge pipe, etc., could
cause cycling.
3. Pump will not remove all water. If operating
a pump manually, and suddenly no water
comes out of the discharge hose, shut off the
unit immediately. The water level is probably
very low and the unit has broken prime.
Risk of electric shock. Can shock,
burn or kill. Before attempting to check why unit
has stopped operating, disconnect power from unit.
Operation 4
2
Slip the float and then the rod stop
onto the rod past the second nib.
1
Mount the bracket onto the switch
housing.
4
Attach the switch to the pump as shown.
Rod
Rod Stop
Float
Bracket
Bracket
Mounting
Screws
Switch
Housing
Pin
3
Insert the rod assembly up into the
switch housing and lock into place
with the pin.
NOTICE Be sure the pin holds the
rod into the switch housing or the
pump will not shut off.
Do Not Change the
preset tether length.
3-1/2"
(89 mm)
Tethered Float Switch
NOTICE For Models 2956 and 2958, see instructions included with replacement switch, Part Number
FPS17-66.
NOTICE
