Simmons SD1 - Side Panel Ports; Rear Panel Connections

SD1 User’s Manual
digital drum kit
6
POWER
ON OFF
9V
KICK
CONTROL
HI-HAT
HI-HAT
 1. 9VPowerConnection–
  Connect9Vadapterhere.
2. Power Switch – Turns the
  poweron/off
 1. Kickjack–Connectincludedpedalor
  othercontrollertoplaykick.
  drums.(Mono)
 2. HI-HATControljack-Connect 
  includedpedalforhi-hattransitions.
 3. HI-HATjack–Connectincludedpedal
crash or cymbal pads to unit.
4. Phoneoutput–Supportsstereo
headphones or an amplifier as an
output device.
SIDE PANEL
REAR PANEL
KICK
HI-HAT
CONTROL HI-HAT
PHONES
1
2
1
3
4
1 2 3 4
1
2
2
