5 MENU SCREENS
The menu structure on the SRM9022 is configurable using the FPP. A system
administrator usually tailors the order and presence of the menu options to specific
customer requirements.
This section describes all the menus that are currently available. It also describes the
Channel Screen, which is the main default screen that is displayed after the radio is
switched on.
Normally, the menus are divided into two menu lists. These are the Main Menu list and
the Setup Menu list.
In the default configuration, the Main Menu contains the Channel, Zone and Setup
menus. This allows access to the second ‘Setup’ menu level.
The Main Menu can be accessed from the default screen by selecting the ‘M’ (F1)
button.
To access any of the menu options from the Main, Setup or User Options Menus, use
the ▲ and ▼ keys to scroll through the lists until the required menu option is
selected with the pointer (►) and then press the ‘OK’ button.
Pressing the ‘Back’ key at any point will go back to the previous screen.
5.1. CHANNEL SCREEN
The Channel Screen shows the current channel and allows channel selection.
Pressing the ‘M’ key enters the Menu mode.
Radio channels may be configured with the FPP as specific frequencies or as auto scan
types. When an auto scan channel is selected, it will immediately go into scan mode.
Selecting another non-auto scan channel will stop the scan.
Doc Number: TNM-U-E-0055 ISSUE 4.0 Page 30
