There are six possible types of Phonebook entries. These are:
Conv.Unit ID (Option 0) Conv.PSTN (Option 1) Conv.Group (Option 2)
Trunk Unit ID (Option 3) Trunk PSTN (Option 1) Trunk Group (Option 4)
Using the keypad, make the required selection (0 – 4) and select OK.
From here, follow the steps for entering the System ID in see 5.6.3.1 below (part of
Section 5.6.3 Phonebook Edit – To Edit an Existing Entry).
5.6.3. Phonebook Edit – To Edit an Existing Entry
This section is used to edit an existing phonebook entry. The operation is similar to
adding a new phonebook entry in previous section.
In this example, editing a P25 Trunked ID is shown. It is also possible to edit a P25
Conventional ID and a P25 Group Entry.
Note:-When editing a phonebook entry for a Conventional channel, not all the steps
will be required.
From the ‘Ph Book Edit’ screen, at the phonebook entry to be edited, press OK and the
‘Ph Book Edit’ pop-up menu will be displayed.
Use the ▼ /▲ keys to select Edit from the pop-up menu and press OK. The ‘Edit Sys ID’
sub-menu screen will be displayed.
5.6.3.1. System ID
Upon entering the Edit Sys ID screen, the current trunked System ID of the selected
phonebook entry is displayed.
Doc Number: TNM-U-E-0055 ISSUE 4.0 Page 38
