Simoco SRM9020 - Completeing a Voice Call Connection; Terminating a Voice Call

SRM9020 ~ Trunked Operating Instructions
TNM-U-E-0012 Issue 2a Page 8 © Comgroup Australia 2010
4.2.1 Completeing a Voice Call Connection
When the called radio is contacted, both radios will
produce a ring tone and the Alert message together
with the call progress icon will be displayed.
When the called person answers, refer to Section 4.3
for information on how to accept a call, both radios
will be connected. The Call Time-Elapsed and audio
enabled icon is displayed.
A conversation can now take place between operators. Each operator must press
and hold down their PTT button to speak and then release it to listen.
4.2.2 Terminating a Voice Call
When the call is finished, either operator can end the call by:
• Replacing the microphone on it’s bracket, or
• Pressing the button.
