SIMOLIO SM-826D - Page 8

Pho nes
AV Receiver
6.35mm Audio adapter
(purchase separately)
3.5mm Audio Cable
6.35mm Phone jack
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN
AUDIO IN
BASS
TREBLE
NORMAL
TONE
Fig 3-22
A
U
D
I
O IN
wireless
transmitter
Coaxial
Digital Out
AUDIO IN
Digital to Analog Converter
RCA OUT
L
R
COAXIAL IN
POWER OUT
DC 5V/500mA
STEREO
MONO
OFF
OFF/ON
DC 5V
POWER IN
OPTICAL IN
AUDIO IN
BASS
TREBLE
NORMAL
TONE
Step 2. TV Audio Format and Speaker Setting (use TV remote control)
If you can not hear sound from your headphones after connecting:
Fig 3-17
• Ensure TV Audio Format is set to “PCM” or “Dolby/DTS” is OFF (This is
IMPORTANT, Ref. Fig 3-18)
PS: for certain smart Samsung models, the TV is retaining separate settings for
regular TV and internet TV setup. When you turn to the Smart Hub for Internet
source, please use the TV remote to go to Settings > Sound > Expert Settings >
Audio Format or Digital Output Audio Format, then select PCM.
• Ensure your TV speaker is set to “External Speakers”. (Ref. Fig 3-19)
• Take turns to test RCA connection and 3.5mm headphone connection.
• Use the AUX/RCA cable to plug the headphone into the headphone or RCA
output of the DAC to test if you can hear the TV sound. (Ref. Fig 3-20)
Fig 3-18 Fig 3-19
Speakers
Internal speakers
External speakers
Headset
Settings
Audio Format
Dolby Digital
DTS
DTS Neo 2:5
PCM
13
12
Note:
Setting menu may be different depending on different TV brands and models.
RCA
OUT
L
R
COAXIAL IN
Connect TV/
Cable box/
STB etc.
RCA Audio Cable
H/P
L
R
COAXIAL IN
3.5mm Audio Cable
Connect TV/
Cable box/
STB etc.
or
Fig 3-20
SM-826D
SM-826D
2) If your TV/Audio Source’s Digital Optical Audio Out port is occupied
by soundbar, you will need an optical splitter for installation.
Step 2. If you can not hear sound from your headphones after connecting,
follow the part of 3.1 on page 8-9 to check your settings.
Step 1. Purchase an Optical Splitter and Set up as Shown in Fig 3-21
Optical Splitter
Optical Fiber
Cable
Sound Bar
Optical Fiber
Cable
SM-826D
(Transmitter)
Fig 3-21
Step 1. Purchase a 6.35mm to 3.5mm Adapter and Set up as Shown in Fig 3-22
3) Connect SIMOLIO SM-826D to your AV Receiver with 6.35mm
PHONE jack
SM-826D is not compatible with ANY RCA(L/R) ports on your AV Receiver,
ONLY use the BIG 6.35mm PHONE OUT on front side of your AV Receiver
with the 6.35mm to 3.5mm adapter (purchase separately).
Digital Optical
Audio Out
• Use the AUX cable and 6.35 to 3.5mm converter to plug the headphone into the
port on AV receiver to check whether the sound is normal.
If you can not hear sound from your headphones after connecting:
Step 2. Check the Performance of the AV Receiver's Audio Output as Shown
in Fig 3-23
03
02
01
03
02
01
03
02
01
