Page 14 579-1019 Rev M
4009 IDNAC Repeater Installation Instructions
Replaceable Devices
Consult the table below for a list of replaceable devices.
Table 8: Replaceable devices
Part
Replacement part
number
Replacement notes
Battery Fuse* 208-099
The battery fuse is a fast acting, 8 A, 32 V fuse and is located in the positive lead of the battery
harness.
AC Input Fuse* (F1) 208-195
The AC Input Fuse is in the line side of the AC input and is a time-delay, 4 A, 250 VAC fuse. It is
located in the fuse holder FH1 under the High Voltage Cover. Shut down AC power and remove the
high voltage cover to replace the fuse.
CAUTION: For continued protection against risk of fire, only replace with the same type and rating of fuse.
