Slot 1 Slot 8Slot 7Slot 6Slot 5Slot 4Slot 3Slot 2
Expansion Bay Chassis
Block A
Block B
Block C
Block D
Block E
Block F
Block G
Block H
Size Definitions: Block = 4” W x 5” H (102 mm x 127 mm) card area
Slot = 2” W x 8” H (51 mm x 203 mm) motherboard with daughter card
Subject Data Sheet Subject Data Sheet
Introducing the 4100ES S4100-0060 Agent Release Applications S4100-0040
4100ES Enclosures S4100-0037 Fire Alarm Network Overview S4100-0055
4100ES Audio and Firefighter Phone Modules S4100-0034 Network Communications S4100-0056
LED/Switch Modules & Printer S4100-0032 Network Display Unit (NDU) S4100-0036
Remote Annunciators S4100-0038 Addressable Device Compatibility S4090-0011
MINIPLEX Transponders S4100-0035 TrueAlert Addressable Products S4009-0003
Building Network Interface (BNIC) S4100-0061 IDNet+ Module w/Quad Isolator S4100-0046
InfoAlarm Command Center S4100-0045 Remote Battery Charger S4081-0002
Graphic I/O Modules S4100-0005 TFX Interface Module S4100-0042
SafeLINC Internet Interface S4100-0028 Master Clock Interface S4100-0033
TrueInsight Remote Service S4100-0063 2120 BMUX Module S4100-0048
9 S4100-0031-21 12/2012
Expansion Bay Module Loading Reference
Description Mounting
IDNet Modules 1 Block
4, 2 A Relays
NON
Power-limited
1 block
4, 10 A Relays 4”, 2 slots
8, 3 A Relays 1 block
VESDA Interface 2”, 1 Slot
Class B IDC 2”, 1 Slot
Class A IDC 2”, 1 Slot
MAPNET II Module 4”, 2 Slots
MAPNET II/IDNet Isolator 2”, 1 Slot
Class B Physical Bridge 2”, 1 Slot
Class X Physical Bridge 4”, 2 Slots
Decoder Module 6”, 3 Slots
System, Remote, or TrueAlert
Power Supply
Blocks E, F, G & H
ONLY
Expansion Power Supply Blocks G & H ONLY
NAC Expansion Module On XPS ONLY
Additional 4100ES Data Sheet Reference
To Next Page
