6500 SERIES PROGRAM RECORD SHEET
LOCATION ___________________________________ DATE ____________________
PULSE LENGTH FOR RELAYS 1,3,4,5,6,7,8 (1-9 SECS) ___ RELAYS PULSED _______________
PULSE LENGTH FOR RELAY 2 (1-9 SECONDS) ___ SECONDARY MODE # ______ (SEE NOTE 1)
BASIC PLAN # _____________ NUMBER OF ENTRIES PER PLAN _______
CUSTOM WEEK SETTINGS (WK0-9) ____________________________________________
R E L A Y S
ENTRY DAYS HH:MM AM/PM
1 2 3 4 5 6 7 8
NOTE 1: When modes other than 0 are selected, relays 3 & 4 are dedicated to correction outputs and are
unavailable for other programming.
