Menu Selection and Response Keys (Cont’d)
Disable/Enable toggles status of the displayed circuit.
Exit/Clear provides a path out of the chosen menu and
allows manual entries to be cleared.
Enter confirms the selection made and enters program
changes into memory.
Left, Previous, Next, and Right arrow keys move the
display cursor or select screens or specific choices,
depending on the displayed functional area.
4005 System Optional Modules
Class A, 4 Circuit Adaptor Module for either IDCs
or NACs (4005-9806):
Individually isolated circuit design adapts either IDCs or
NACs for Class A operation allowing a combination of
circuit types
Mounts on top of the module, maintaining full module
capacity
Power Distribution Module (4005-9807):
Extends 4005 capacity to ten plug-in modules
Mounts on left side of 4005 chassis
Required when plug-in module requirements extend
beyond five and/or for connection of expansion power
supply 4005-9813
City Circuit Module (4005-9809):
Single circuit, selectable as local energy, reverse
polarity, or form “C” contact
Reverse polarity is selectable for Alarm/Trouble, Alarm,
Supervisory, or Trouble only reporting
Up to two modules mount directly to 4005 chassis below
the CPU assembly
Expansion Power Supply (4005-9813):
Provides power-limited and regulated 24 VDC to
Expansion Module 4005-9807; rated 5 A for Special
Application Appliances and 2 A for Regulated 24 DC
power
Installs on the left side of the 4005 chassis and fits
behind expansion modules, allowing full module
capacity
Switch selectable for 120 VAC or 240 VAC
Provides additional power for notification appliances,
4-wire detectors, annunciator power, or other fire alarm
auxiliary functions
4005 System Capacity Expansion Modules
Optional and expansion modules can be easily installed and
programmed on-site. Their “snap-in-place” design installs
without tools or hardware, allowing configuration for the
initial system capacity or for later system expansion.
2 Circuit IDC with 2 Circuit NAC/Relay
(4005-9803):
Two, standard low current IDCs, for up to 20 detectors
per IDC, 2 mA maximum
Capacity Expansion Modules (Continued)
Two circuits, individually on-site selectable as either
Class B NAC, or N.O. or N.C. relay circuits
Combined on one plug-in module
Operation and programming is the same as the standard
control panel IDCs and NAC/Relay circuits
4 Circuit IDC Module (4005-9804):
Four, standard low current IDCs on one plug-in module,
for up to 20 detectors per IDC, 2 mA maximum
Operation and programming is the same as the standard
control panel IDCs
4 Circuit NAC/Relay Module (4005-9805):
Four, NAC/Relay Circuits on one plug-in module
Operation and programming is the same as the standard
control panel NAC/Relay circuits
8 Circuit I/O Module (4005-9808):
Select each circuit as either an input or output
Input mode supervises hard wired connections to 4601
Series annunciator switches or utility switch inputs
Output mode is rated 24 VDC, 150 mA open collector
driver, short circuit protected, UL listed for pilot duty
Output mode provides supervised auxiliary control of a
compatible annunciator or remote relay for emergency
control in accordance with NFPA 72 and NFPA 101
4 Circuit IDC, High Current, Required for
Detectors with Relay Bases (4005-9824):
Four, high current IDCs on one plug-in module
High current operation for up to 30 detectors per IDC,
3 mA maximum detector power (required for detectors
with relay bases)
Operation and programming is the same as the standard
control panel IDCs
Accessories
4602 Series Annunciators:
Supervised serial communications using twisted,
shielded pair
SCU has 16 LED zone status indicators
RCU has 8 LED zone status indicators, Power-On LED
and Trouble LED, Local tone-alert, and keyswitch
enabling of Trouble and Alarm Silence, System Reset,
and Manual Evacuation
4601 Series Annunciators:
Provides LED status indications and switches for
acknowledge, silence, and reset
Modular design allows sizing as needed
4005-9150 and 4002 Adapter Kits for Retrofit:
Replace existing 4002 Fire Alarm Control Panels with
the 4005 panel features, supplied with high current IDC
modules for convenient retrofit
Cabinet, door, and electronics may be ordered separately
to satisfy early cabinet (backbox) installation
requirements
5 S4005-0001-9 3/2009
