Simplicity
Assembly
CONTENT
OF
SECTION
The
rotary
tiller
is
shipped
only
partially
assembled
for
packaging
reasons.
This
section
provides
the
necessary
instructions
for
assembling
the
rotary
til¬
ler
and
for
preparing
it
for
operation.
TO
UNCRATE:
Open
the
top
of
the
shipping
car-;
ton
and
remove
all
loose
parts.
Then
slit
the
sides;
of
the
carton
and
slide
the
tiller
out
of
the
box
on
the
skid.
Cut
banding
and
remove
unit
from
skid.
HA
NDLE
ASSEMBLY
__
Remo
ve
all
parts
from
their
conta
i
ners
and
arrange
am
IpartsJby
size
and^ype..
Remove
tape
to
remove
control!
Irodsand
lab®rom
h
Jidfes,
lj|r
1.
I
nstall
the
left-hand
side
(the
one
with
the
REVERSE
decal)
of
the
handlebar
assembly
first.
Align
handle
slotted
hole
(item
A,
fig¬
ure
22)
with
frame
hole
(item
B)
and
insert
a
plain
capscrew
(item
C)
through
frame
and
handlebar.
Add
a
flat
washer
and
lockwasher
(items
D
and
E),
and
install
hex
nut
(item
F)
finger
tight.
2.
I
nsert
a
special
washer
headed
capscrew
(item
G)
through
the
frame
only
at
the
top
hole
of
left
handle.
Add
two
washers
(item
H)
be¬
tween
frame
and
handle
and
push
capscrew
through
handle.
Adda
lockwasher
(item
I)
and
finger
tighten
nut
(item
J)
in
place.
Figure
22.
Left
Handle
Asse
mbly
3.
Repeat
steps
1
and
2
for
the
right
side
of
handlebar.
Tighten
all
nuts
finger
tight.
4.
The
slotted
holes
(item
A)
are
for
adjusting
handlebar
height.
Select
a
desired
height
and
then
securely
tighten
all
four
nuts
(handles
may
need
readjusting
after
tines
are
installed).
5.
Push
the
throttle
control
lever
on
the
left
handle
all
the
way
down
to
the
SLOW
posi¬
tion.
6.
Run
throttle
cable
between
handles
and
along
the
right
frame
to
side
of
engine
(for
1005)
or
to
front
of
engine
(for
1003).
Hook
throt¬
tle
cable
(item
A,
figure
23)to
throttle
pivot
(item
B).
7.
Loosen
the
clamp
(item
C)
and
slip
the
cable
under
the
clamp.
Pull
the
cable
back
(for
model
1005)
or
down
(for
model
1003)
as
far
as
it
will
go
and
tighten
the
clamp
to
hold
cable
in
place.
Operate
throttle
lever
to
be
sure
pivot
moves
throughout
its
full
range.
Figure
23.
Throttle
Cable
Assembly
