Simplicity 1693080 Service And Repair Manual

9 - 3
9 Drive Controls Service
Tuff Torq K-56 Models
Ref. Qty. Description
1 1 KNOB, Plastic, Parking Brake
2 1 ROD, Parking Brake
3 3 SPACER
4 3 FLANGE NUT, Locking, 5/16-18
5 1 SPRING, Brake Return
6 1 LOCK NUT, Center, 1/4-20
7 2 LOCK NUT, Flange, 1/4-20
8 2 SPACER
9 2 CAPSCREW, 1/4-20 x 1
10 1 BRAKE LINK
11 1 BRAKE ARM
12 1 GUIDE, Brake Rod
13 1 ROD, Brake
14 5 LOCK NUT, Nylon, 5/16-18
15 5 WASHER, Plain, 5/16
16 1 SPRING
17 1 CAPSCREW, 3/8-16 x 1-3/4
18 1 LOCKWASHER, 3/8
19 1 WASHER, Plain, 3/8
20 1 GUARD
21 1 PULLEY, Idler, V
22 2 BUSHING, 5/8
23 2 COTTER PIN, 1/8 x 3/4
24 1 NUT, Hex, Flange Whiz, 3/8-16
25 2 SPRING
26 1 PULLEY, Backside Idler
27 1 BRACKET, Idler
28 1 CARRIAGE BOLT, 3/8-16 x 1-3/4
29 1 CARRIAGE BOLT, 5/16-18 x 1
30 1 WASHER, Plain, 1/4
31 1 LEVER, Parking Brake
32 1 ROD, Clutch
33 1 NUT, Hex, 5/16-18
34 1 LOCKWASHER, 5/16
35 1 CLAMP, Tube
36 4 CARRIAGE BOLT, 5/16-18 x 3/4
37 1 PAD, Foot Pedal, Forward
38 1 FOOT PEDAL ASSEMBLY
39 1 PAD, Foot Pedal, Brake
40 1 PAD, Foot Pedal, Reverse
41 1 ROD, Control
42 2 STUD, Shock Mounting
43 1 SHOCK ABSORBER
Drive Controls Components - Tuff Torq K-56 Models
