Simplicity 1693080 Service And Repair Manual

7 - 9
7 Electrical System Service
Wiring Diagram
Peerless Models (1998 and Later)
PTO
ELECTRIC CLUTCH
P/N 1708536
MAGNETO
IGNITION SWITCH
POSITION
1. OFF
2. RUN
3. START
CIRCUIT MAKE
G & M & A
B & L & A
B & L & S
A
M
L
G
B
S
FUEL SHUTOFF
SOLENOID
N.O.
N.C.
PEDAL SWITCH
P/N 1714770
PTO SWITCH
P/N 1714772
PEDAL SWITCH
P/N 1704379
(BACK OF)
IGNITION
SWITCH
P/N 1716061
N.C.
TRANSMISSION SWITCH
P/N 1654634
STARTER
B
S
SOLENOID
P/N 1685290
HEADLIGHT
SWITCH
P/N 1703799
BATTERY
P/N 1685290
CIRCUIT
BREAKER
P/N 1665238
N.C.
SEAT SWITCH
(UNOCCUPIED)
P/N 1714771
SPLICE
“A”
SPLICE
“B”
SPLICE
“C”
SPLICE
“D”
ALTERNATOR
LIGHT BLUE/RED
LIGHT BLUE/RED
BLACK/RED
RED/WHITE
RED/WHITE
PURPLE
BLUE
RED / WHITE
BLUE
RED RED
YELLOW BLUE
TAN
RED
RED
RED
TAN
TAN
TAN
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
GRAY
GRAY
GRAY LIGHT BLUE/RED
BLACK
RED
RED
TAN
YELLOW GREEN
GREEN
GREEN
YELLOW
YELLOW
PURPLE
PURPLE
PURPLE
ORANGE ORANGE
BLACK
PURPLE
(PEDAL UP)
(TRANSMISSION
IN NEUTRAL)
