16 - 13
16 Mower Deck Service
44” Mower Deck - Belt, Idler Arm, & Hitch
Ref. Qty. Description
1 1 V-BELT
2 1 CAPSCREW, Hex, 3/8-16 x 2-1/2
3 3 WASHER, 3/8
4 1 PULLEY ASSEMBLY
5 1 SPACER
6 1 GRIP, Lever
7 1 ARM, Idler
8 1 LOCKWASHER, Spring, 3/8
9 1 NUT, Hex, 3/8-16
10 1 NUT, Hex Flange Lock, 3/8-16
11 1 SPRING
12 1 NUT, Hex, Center Lock, 3/8-16
13 2 WASHER
14 1 SPACER, Idler Arm
15 1 CAPSCREW, 3/8-16 x 1-1/4”
16 2 CAPSCREW, Hex, 3/8-16 x 1-1/2
17 2 SPACER
18 1 WASHER, 7/16 x 1-1/4 x 1/8
19 2 NUT, Hex Lock, 3/8-16
20 1 ROD, Mower Hitch
21 1 ROD, Latch
22 1 HITCH
23 1 NUT, Push, 1/2
24 1 SPRING
44” Mower Deck - Belt, Idler Arm, & Hitch
