8 - 3
8 Steering Component Service
Steering System Components
Ref. Qty. Description
1 1 STEERING WHEEL ASSY., (Incl. CAP Ref. 2)
2 1 CAP, Steering Wheel
3 1 TUBE, Flex
4 1 PIN, Spring, 5/16 x 2-1/2
5 1 SHAFT ASSY., Steering
6 2 CARRIAGE BOLT, 3/8-16 x 1
7 4 WASHER
8 2 NUT, Flange Lock ,Whiz, 3/8-16
9 1 CAPSCREW, 3/8-16 x 1-1/4
10 1 WASHER
11 1 STEERING GEAR ASSY.
12 1 DRAG LINK
13 3 NUT, Hex, Flange Lock. 3/8-16
14 3 KLIPRING
15 1 ARM, Steering, LH
16 2 WASHER
17 2 SPINDLE ASSY.
18 2 SPACER
19 1 PIN, Cotter, 3/16 x 1-1/4
20 1 TIE ROD
21 1 ARM, Steering, RH
22 2 CARRIAGE BOLT, 3/8-16 x 1-1/4
23 1 CARRIAGE BOLT, 5/16-18 x 1
24 1 SPACER
25 1 NUT, Hex, Flange Lock, 5/16-18
26 2 SCREW, Taptite, 5/16-18 x 3/4
27 1 BUSHING
28 1 BUSHING
29 1 PLATE, Steering, Mounting
Steering System Components
