Simrad AP50 Operator's Manual

Simrad AP50 Autopilot
8 20221032 / E
RI9 Rudder Angle Indicator
The RI9 is manufactured in non-corrosive aluminium with a non-
reflective black finish. The indicator is made in standard modular
size (144x144 mm).
It is designed to operate from both voltage and current signals.
The instrument gives a continuous reading of the rudder angle up
to 45 degrees on either side of the midship’s position. (60, 70 or
90° as option).
The water tight construction allows bulkhead or desk mounting in
exposed locations, such as bridge wings as well as wheelhouse
and engine room.
NI300X NMEA Interface Unit
This interface unit with 4 NMEA In/Out ports for
communication with other systems and a selectable heading
output for radars (Anritsu or Furuno), includes two Robnet
connectors for the AP50 system.

Simrad AP50 Specifications

General

Brand	Simrad
Model	AP50
Category	Autopilot System
Language	English
