CP42/50/52 Position menus Chapter 4
41
S 6.2
kn
V 4.8
kn
W 2.2
kn
[kn] 22:03 22:08
10
8
6
4
2
0
SD:S *.*kn T *° R *° WIND: *.*ms *°R
4.4 Speed diagram
MENU
Call up the menu bar, and…
2,4
load “Speed diagram”
S= Speed over ground.
V= Velocity towards waypoint.
W*= Speed through water.
SD (Set and drift)*= Speed and direction, true or relative.
WIND*= Speed and direction.
* Connection to external sensors is required.
ENT
Call “Speed diagram setup”
- see next page
