Chapter 10-2 EQ44/54 SETUP menu
Echosounder setup:
Select transducers:
TYPE PORT
Transducer 1: NONE ECHO1
Transducer 2: NONE ECHO2
BEAM ANGLE DEPTH
Keel depth below surface: 00.0 m
Display: DEPTH BELOW KEEL
Data on NMEA-out from: NONE
Alarm for fish: Strength: 065% OFF
Depth DS fish: min: 0005 m max: 0030 m
Depth DK alarm min.: 0005.0 m OFF
Depth DK alarm max.: 0030.0 m OFF
Water profile: SALT
Velocity of sound in water: 1470m/s
Time/distance scale: ON
Restart of AUTO pulse/power: 20 sec.
Echo sampling: BOTTOM
Demo mode: OFF
MENU
Exit Accept
ENT
Use the cursor key to move cursor around in the display
+/-
Select new values by means of the +/- keys
ENT
Confirm changes, or...
MENU
Abandon changes and exit display
Transducer - select transducer type. Insert the depth (position) of
the transducer below surface.
Display can show: DEPTH BELOW KEEL / SURFACE / TRANS-
DUCER.
Data on NMEA-out from - select the frequency you wish to use for
transfer of data to connected navigator, plotter, etc.
Alarm for fish - set the strength from min. 000 (weak echo) to max.
099% (strong echo), and you can set it ON or OFF.
