EQ44/54 PILOT menu Chapter 8-1
8. PILOT menu
5
PILOT
1
Highway
2
Position
8.1 Highway display
To present any information in the EQXX highway display will
require that a navigator is connected via SimNet or the NMEA input
port - refer to section 11.5 Electrical connections.
 The connected navigator must be in navigation mode, which
could be Cursor, Waypoint, Route or Track navigation - see next
page.
8.1.1 Navigation setup
MENU
Call up the menu bar, and...
5,1
load Highway display
Since there is no navigation mode active, you will receive the legend:
NAVIGATION IS OFF. To enter the basic Navigation setup:
ADJ
Load Navigation setup
Navigation setup:
XTE distance: 00.10nm
Alarm distance can be changed in this display, but alarm can only be
initiated from the connected navigator. Maximum setting in nautical
miles is 9.99 nm.
