Installation | HS60 GPS Compass User Guide
Warning: Over-tightening may damage the system. This is
not covered under warranty.
Pole mounting instructions for HS60 (Outside Pole)
Required tools: 5 mm Allen key for M6 screws and adjustable
wrench to tighten jam nut.
1.
Place the jam nut on the pole followed by the 1” (25.4 mm) adapter base.
Hand tighten the base to the desired orientation.
2. Adjust the jam nut to secure the orientation.
3. Run the cable throughout the vessel making sure to leave enough slack
to mate the NMEA 2000 cable to both the NMEA 2000 backbone and the
HS60 unit.
4. Run the NMEA 2000 cable through the opening in the side of the pole
mounting adapter. And then connect the mating end of the cable to the
V104 connector located on the bottom of the unit.
5. Insert the base adapter into HS60 by placing the tongue of the base into
the groove of the HS60 unit. When the tongue is properly seated in the
groove, the rest of the base can be pressed into place to create a smooth
seam between the base and HS60 unit.
6. Use 5 mm Allen key to fasten two M6 screws to secure HS60 onto adapter.
Use 15 in-lb torque
7. Insert each o-ring onto a plastic cap
8. Install plastic cap with o-ring onto HS60 unit (rectangular notch faced
towards the outside)
9. Align and set the direction of HS60 unit, while using the jam nut to secure
the unit (hand-tighten).
Warning: Over-tightening may damage the system. This is
not covered under warranty.
Connecting the NMEA 2000 cable
1. Align the NMEA 2000 cable connector key-way with the HS60 connector
key.
