Technical specifications
NAC-2
Approvals
Compliance EMC directive 2014/30/EU
Electrical
Supply voltage 9-31.2 V DC
Power consumption - Max 500 W
Power consumption - Typical As required to drive rudder
actuator. See pump/motor
power ratings
Recommended fuse rating 20 A
Environmental
Operating temperature -25°C to +55°C (-13°F to 131°F)
Storage temperature -30°C to +70°C (-22°F to 158°F)
Waterproof rating IPx5
Humidity 100%
Shock and vibration Acc to EN60945
Connectivity
NMEA 2000 1 Micro-C port, 1 LEN
Drive 12/24 V DC, min 10 mA, max 3 A
Rudder Feedback Variable voltage/resistive 0‐5 V
NMEA 2000 PGNs See "NMEA 2000 PGNs" on page 38
Physical
Dimensions See "NAC-2" on page 37
Weight 0.6 kg (1.3 lbs)
Compass Safe Distance 500 mm (20 inches)
Warranty 2 years
7
34
Technical specifications | NAC-2/NAC-3 Commissioning Manual
