Rudder Rudder angle, frequency input.
15 V, 1.4 to 5 kHz, resol. 20 Hz/°
Remote • Input: External open/
close contact for remote
controller
• Output: High/Low mode
indicator signal
Mode External open/close
or pulse contact for autopilot
disengage
Alarm External alarm output for
buzzer/relay. Max 100 mA,
voltage level as local supply
Physical
Dimensions See "NAC-3" on page 37
Weight 0.7 kg (1.6 lbs)
Compass Safe Distance 500 mm (20 inches)
Warranty 2 years
36
Technical specifications | NAC-2/NAC-3 Commissioning Manual
