Dockside setup
Data source selection
Before commencing with autopilot computer setup the data
sources must be available and configured.
Data sources selection is required on initial start-up of the system, if
any part of the network has been changed or replaced, or if an
alternative source is made available for a given data type and this
source has not been selected automatically.
You can let the system automatically select your sources, or set up
each source manually. Refer to documentation for the autopilot
controller or for the display unit for details about how to perform
the data source selection.
Boat characteristics
Boat type
Affects steering parameters as well as available autopilot features.
The following options are available:
• Sail
• Displacement
• Planing
Ú
Note: If the boat type is set to Sail, Virtual Rudder Feedback is
not available.
Boat length
Used by the autopilot system to calculate steering parameters.
Cruising speed
Used if no speed info is available. It is used by the autopilot system
to calculate steering parameters.
Drive configuration
The drive configuration controls how the autopilot computer
operates the steering system.
Refer to your drive unit documentation for relevant specifications.
2
10
Dockside setup | NAC-2/NAC-3 Commissioning Manual
