NAC-3
Approvals
Compliance EMC directive 2014/30/EU
Electrical
Supply voltage 12/24 V DC +/- 10-30%
Power consumption - Max 750 W
Power consumption - Typical As required to drive rudder
actuator. See pump/motor
power ratings
Recommended fuse rating 30 A
Environmental
Operating temperature -25°C - +55°C (-13°F - 131°F)
Storage temperature -30° - +70°C (-22°F - 158°F)
Waterproof rating IPx5
Humidity 100%
Shock and vibration Acc to EN60945
Connectivity
NMEA 2000 1 Micro-C port, 1 LEN
NMEA 0183 1 port IN/OUT. 4.8, 9.6,
19.2 & 38.4 kbaud
Drive • Reversible motor control
of rudder.
Max continuous load 30
A, peak 50 A for 1s
or
• On/off
solenoid control of rudder.
12/24 V DC,
common, load range 10
mA to 10 A, off current <1 mA
Engage Output for bypass/clutch. 12/24
V DC, min 10 mA, max 3 A
Technical specifications | NAC-2/NAC-3 Commissioning Manual
