Installation verification
When all units in the autopilot system are installed, external
equipment connected and the software configured according to
the previous chapters, the installation should be verified according
to the checklist. The boat specific settings should be noted down in
the relevant tables included this chapter.
Checklist
Description Reference
Units mounted and secured
according to instructions
Installation instructions for the
units
Network powered and
terminated according to
instructions
Wiring instructions for the units
Sources selected
Autopilot control unit
documentation
Vessel configured "Boat characteristics" on page 13
Drive units configured and
calibrated
"Drive configuration" on page 14
Compass calibrated "Compass setup" on page 16
Seatrial completed (manual or
autotune)
"Sea trial" on page 16
Boat specific settings
Boat
Settings
Boat type
Boat length
Cruising speed
Transition speed
5
28
Installation verification | NAC™ -D Commissioning
