Cable retainer installation
With the cable and plug fitted in place, secure the cable to the retention bracket using a
cable tie. Do not secure in such a way that it applies strain to the cable, or causes the plug or
socket to be bent out of alignment.
Panel mounting
Refer to the separate mounting template for panel mounting instructions.
Bracket mounting
For bracket mounting refer to separate documentation supplied with the bracket kit (sold
separately).
Installation | NSO-evo3 Installation Manual
11
