Technical specifications
Display
Resolution 1920 x 1080
Brightness 1000 nits
Touch screen Full touch screen (multi-touch)
Viewing angles in degrees (typical value at
contrast ratio = 10)
80° top/bottom, 80° left/right
Electrical
Supply voltage 12/24 V DC (10 - 31.2 V DC min - max)
Power consumption - Max
16" unit 40 W +- 4 W
19" unit 50 W +- 4 W
24" unit 80 W +- 5 W
Recommended fuse rating
16" unit 6 A at 12 V DC / 3 A at 24 V DC
19" unit 7 A at 12 V DC / 4 A at 24 V DC
24" unit 10 A at 12 V DC / 5 A at 24 V DC
Environmental
Operating temperature range -15°C to +55°C (5°F to 131°F)
Storage temperature -20°C to +60°C (4°F to 140°F)
Waterproof rating IPX6 (when panel mounted correctly with
only the front exposed)
Humidity IEC 60945 Damp heat 66°C (150°F) at 95%
relative (48 hr)
Shock and vibration 100 000 cycles of 20 G
Interface/Connectivity
Ethernet 3x (RJ45)
USB 3x (USB-A)
J1393 1x (Micro-C)
NMEA 2000 1x (Micro-C)
NMEA 0183 4 ports
Video output 1x high definition video output (1080p, no
HDCP, HDMI-A)
Video input 2x composite video (BNC)
1x high definition video (1080p, HDCP 1.4,
HDMI-A)
Data card reader 1x slot (microSD)
Wireless Internal 802.11b/g/n
Physical
Dimensions (W x H x D) Refer to "Dimensional drawings" on page 45
Weight (display only)
16" unit 3.9 kg (8.6 lbs.)
19" unit 4.8 kg (10.5 lbs.)
24" unit 7.8 kg (17.2lbs.)
Compass Safe Distance - Metric, imperial 50 cm
Appendix | NSO-evo3 Installation Manual
43
