Software setup
First time startup
When the unit is started for the first time, or after a factory default, the unit displays a series of
dialogs. Respond to the dialog prompts to make fundamental settings.
You can perform further setup and later change settings using the system settings dialogs.
Software setup sequence
1 General settings - refer to "System settings" on page 20.
• Make general settings as desired
• Configure the power control
2 Advanced settings - refer to "Advanced" on page 21.
• Enable or disable features
• Review the advanced setting options and make changes as desired
3 Source selection - refer to "Network settings" on page 31.
• Make sure that the proper external data sources have been selected
4 Feature setup
• Configure specific features as described later in this chapter
Accessing the settings dialog
The following sections focus on settings that typically do not require change once
configured. The software setup is done from the Settings dialog which can be accessed from
the home page.
System settings
Time and date
Configure time settings to suit vessel location, along with time and date formats.
Configure WheelKey
Configures the action of the WheelKey on the front of the unit.
Power control setup
Determines unit response to signal applied to the power control wire. Refer to "Power control
connection" on page 13.
4
20
Software setup | NSO-evo3 Installation Manual
