Simrad R5000 Installation Manual

LWE details
LWE Input messages
System function Transmission group Talker ID Sentences
BAM to Radar Selectable VDRD, BAM1,
BAM2, CAM1 or CAM2
- cc - ACN, HBT
High update rate
navigational data
SATD - cc - THS, HDT
Navigational data NAVD - cc - VBW, VHW, DTM,
GLL, GGA, GNS,
DTM, VTG
AIS target data to radar TGTD - cc - VDM, VDO
SNGF MISC - cc - Unrestricted,
(max. serial port
buffer capacity:
1023 bytes)
TIME TIME - cc - ZDA
Network administration NETA - cc - SRP
- cc - Received talker identifier as per NMEA®.
- BAM 1 is the default transmission group to interface the BAM.
LWE Output messages
System function Transmission group Talker ID Sentences
Radar target data TGTD RA TTM, TTD, TLB
Radar alert source to BAM Selectable VDRD, BAM1,
BAM2, CAM1 or CAM2
RA ALC, ALF, ARC,
HBT
Navigational data NAVD RA OSD, RSD
SNGF MISC SI As per input in
COM1, COM2,
COM3 and
COM4
Network administration NETA SI for each SNGF,
RA for the
system
SRP
- BAM 1 is the default transmission group to interface the BAM.
LWE Binary Image transfer
System function Transmission group Talker ID
Binary Image to VDR Selectable transfer group 1, 2, 3, 4,
5 or
NAVD
RA
VDR acknowledgement to Radar VR
- Transfer group 1 is the default transfer group to interface the VDR.
Destination multicast Addresses and Port Numbers
Transmission group Category Multicast
address
Destination
port
MISC Data sharing (SNGFs) 239.192.0.1 60001
