Transmission group Category Multicast
address
Destination
port
TGTD AIS target data, Radar
tracked target messages
239.192.0.2 60002
SATD Ship heading 239.192.0.3 60003
NAVD EPFS (GPS), Speed 239.192.0.4 60004
VDRD Data required for the VDR 239.192.0.5 60005
TIME Time and Date 239.192.0.7 60007
BAM1 BAM compliant alerts
source
239.192.0.17 60017
BAM2 BAM compliant alerts
source
239.192.0.18 60018
CAM1 BAM compliant alerts
source
239.192.0.19 60019
CAM2 BAM compliant alerts
source
239.192.0.20 60020
Transfer group 1 Re-transmittable binary
file transfer
239.192.0.26 60026
Transfer group 2 Re-transmittable binary
file transfer
239.192.0.27 60027
Transfer group 3 Re-transmittable binary
file transfer
239.192.0.28 60028
Transfer group 4 Re-transmittable binary
file transfer
239.192.0.29 60029
Transfer group 5 Re-transmittable binary
file transfer
239.192.0.30 60030
NETA Network administration,
e.g SFI collision detection
239.192.0.56 60056
Alphabetic alert list
Alert type abbreviations:
• C: Caution
• W: Warning
• A: Alarm
Alert text Description Type
Cate-
gory
Alert
ID
AIS Capacity
95%
AIS target processing/displaying is about to
be exceeded.
C B 3043
AIS Capacity Full AIS capacity exceeded. W A 3042
AIS FAIL
AIS failure. W B 3015
Not used. AIS failure. C B 10194
AIS TGT in GZ AIS target in guard zone. W A 3048
AIS TGT Lost: # AIS target # is lost. W A 3052
BAM HBT Lost BAM heartbeat lost. C B 10000
Bearing Pulse
FAIL
Bearing pulse fault. W B 16016
Dangerous AIS
TGT
CPA or TCPA values of an activated AIS target
less than set limits.
A A 3044
