Simrad R5000 Installation Manual

Alert text Description Type
Cate-
gory
Alert
ID
Dangerous TT
CPA or TCPA values of a tracked target less
than set limits.
A A 3044
Door Switch
Open
The radar enclosure is open due to
maintenance. The radar is not operational.
A A 3015
EPFS FAIL
Position source failure. W B 3015
Not used. Position source failure. C B 10194
Gateware FAIL Gateway datapath error. W B 16026
Geodetic Datum
FAIL
Geodetic datum failure. W B 3015
GYRO FAIL
Gyro failure. W B 3015
Not used. Gyro failure. C B 10194
Heading Line
FAIL
Heading line failure. W B 3015
Magnetron EOL Magnetron end of life reached. C B 10195
Mechanical FAIL Mechanical fault. W B 16032
Motor driver
FAIL
Motor driver failure. W B 16045
Motor FAIL Motor not running. W B 16017
Motor or
Antenna FAIL
Motor stall. W B 16036
PM System FAIL Performance monitor failure. W B 16047
POSN Invalid Position invalid. W B 3015
POSN
Unavailable
Position unavailable. W B 3015
PSU Hardware
FAIL
PSU hardware fault. W B 16030
PSU Overheat
FAIL
PSU overheat. W B 16027
PSU Power FAIL PSU power. W B 16029
PSU Voltage FAIL PSU voltage. W B 16028
Radar Antenna
FAIL
Radar antenna failure. W B 3015
RADAR FAIL Radar TXRX failure. W B 3015
Radar
Persistence FAIL
Persistence corrupt. W B 16015
REF TGT Lost Reference target lost. W A 3052
Safety Switch
Open
The safety switch is open due to
maintenance. The radar is not operational.
A A 3015
Scanner Config
FAIL
Scanner config fault. W B 16022
SOG FAIL
Speed Over Ground failure. W B 3015
Not used. Speed Over Ground failure. C B 10194
Speed LOG FAIL
Speed log failure. W B 3015
Not used. Speed log failure. C B 10194
SPD Long. Axis
FAIL
Speed longitudinal axis data failure. W B 3015
