Simrad R5000 Installation Manual

Wiring
System example
A
L
G
I
JJ
K
FF
HH
B
CC
Description
A Radar sensor
B Antenna
C SRT LAN up-mast or HALO transceiver
F R5000 power supply unit
G M5000 monitor
H R5000 radar processor
I O5000 trackball
J O2000 controller or expanded keyboard
K O2000 power supply unit
L R5000 control station
M Managed switch
N Lightweight Ethernet sensor (LWE IEC 61162-450)
O VDR
3
Wiring | R5000 radar processor Installation Manual
9
