Simrad RI9 - Page 23

Instruction manual
20220562E 21
VOLTAGE FB
SUPPLY +
2x1,5 sq.mm
3x1,5 sq.mm
TOTAL NUMBER OF INDICATORS: 4
RUDDER ANGLE INDICATORS
RI9
RI9
RI9
PANORAMA Mk2
31254
2x1,5 sq.mm
MAINS
110-220V 50-60Hz
RI4
RECTIFIER BOX
STANDARD
RUDDER POT. METER
1
23
110V
220V
123
4
5
6
SUPPLY -
VOLTAGE FB
SUPPLY +
SUPPLY -
VOLTAGE FB
SUPPLY +
SUPPLY -
U
Fig. 2-10 Wiring diagram
Panorama Mk2 and RI9 on AC Mains using a Robertson RI4 Rectifier
and “Standard Rudder Potentiometer”
