| 15
General Information | RS40/RS40-B User Guide
During normal operation, the following icons may be displayed on
the screen depending on setup:
Symbol Meaning
Radio is transmitting
Receiver busy with incoming signal
Low Transmit power selected (1W)
High Transmit power selected (25W)
Current channel is Duplex (off when Simplex)
Current channel is receive only
Local mode enabled (used when in areas of high radio traffic, i.e. inner harbour)
Channel is saved as a favourite
Channel will be skipped during a scan
Weather channel stored by user (EU & INT country modes only)
Channel bank is set to USA
Channel bank is set to International. (Channels available depends on selected
country mode)
Channel bank is set to Canada
ATIS functionality is enabled (EU country mode only - must be enabled when in
European inland waterways)
DSC functionality is enabled
DSC functionality is enabled, auto switch is turned off
AIS function is enabled - Receive only mode
AIS Class-B function is enabled – Transmit and Receive mode (RS40-B only)
AIS Class-B Silent Switch mode is active – AIS transmissions are disabled (RS40-B
only)
Internal GPS is enabled, with valid 3D fix
Internal GPS is enabled, no fix
External GPS is enabled, with valid 3D fix
External GPS is enabled, no fix
Weather alert enabled (USA/CAN only)
Missed DSC call
Low Battery (vessel) warning (activates at 10.5 V)
Battery level (wireless handset)
Track your Buddy feature is active
Current channel is selected as the Watch channel
GPS simulator is active
