Specications | RS40/RS40-B User Guide
Specications
GENERAL
Power supply: 12 V DC battery system
Nominal operating voltage: + 13.6 V DC
Low battery alert: 10.5 V DC +/- 0.5 V
Over voltage protection: > 15.8 V +/- 0.5 V
Current drain (transmit): ≤ 6 A @ 25 W / 1.5 A @ 1W (12 V DC)
Current drain:
- RS40 (receive): Less than 760 mA in standby
- RS40-B (receive): Less than 850 mA in standby
Replacement fuse: 8 A, Glass type 3 AG; 32 mm (1.25”)
Temperature range: -20 ºC to +55 ºC (-4 ºF to 131 ºF)
Usable channels: International, USA, Canada, Weather
(country specific)
Mode: 16K0G3E (FM) / 16K0G2B (DSC)
DSC mode: Class D (Global) with dual receiver
(individual CH70)
Standards - EU: EN 60945:2002, EN 60950-1:2006
+A11:2009+, A1:2010+A12:2011
+A2:2013, EN 62311:2008, EN 301
843-1 V2.2.1, EN 301 489-1 V2.1.1,
Draft EN 301 489-5 V2.2.0, EN 301
489-17 V3.1.1, Draft EN 301 489-19
V2.1.0, EN 301 025 V2.2.1, EN 300
698 V2.2.1, EN 303 413 V1.1.1,
EN 300 328 V2.1.1
Standards - US/CAN: US/CAN: FCC Part 80, RSS-Gen Issue
5, RSS-182 Issue 5, FCC Part 18
Standards - INT: AS/NZS ETSI EN 301 025
Standards - AIS: ITU-R M.1371-5, IEC 62287-1, IEC
61162-1, IEC 61162-2, IEC 61108-1,
IEC 61108-2, IMO Resolutions
A.694(17) and MSC.74(69) Annex 3
Frequency range,
- Transmitter:
- Receiver:
156.025 - 157.425 MHz
156.050 - 163.275 MHz
Channel spacing: 25 KHz
10

Simrad RS40 Specifications

General

Type	VHF Marine Radio
Display	LCD
AIS Receiver	Yes
NMEA 2000	Yes
Waterproof Rating	IPX7
Output Power	25W
NMEA 0183	Yes
Modulation	FM
Power Supply	12V DC
DSC	Class D
Channels	International, US, Canadian
GPS	Built-in
Frequency Range	156.025 MHz to 162.025 MHz
Weight	1.2 kg
