Simrad RS40 User Manual

| 53
Installation | RS40/RS40-B User Guide
Installation
What’s in the box
The following items should be supplied in the box. Check before
starting the installation and contact your dealer if an item is missing.
1
2 3
4
5
6
7
8
9
10
11
1. VHF radio
2. Removable hand mic
3. Bracket for gimbal mounting
4. Gasket for recessed mounting
5. Sun cover
6. Knobs for bracket
7. Bezel trim
8. 8 A (3 AG) spare fuse
9. Bulkhead mount for hand mic
10. 2 pcs 3.5 x 20 mm, stainless steel, panhead Phillips
11. 8 pcs 4 x 25 mm, stainless steel, panhead Phillips.
12. Documents: user’s manual, warranty card, mounting template.
Before you start:
• A VHF antenna is not provided. Consult your Simrad dealer for advice
on selecting the correct antenna for your installation.
• This radio must only be connected to a 12V DC, Negative ground
power source.
• Do not install in a Hazardous / Flammable environment.
9
ENGLISH
Installation Manual
bandg.com
ENGLISH
Installation Manual
bandg.com
ENGLISH
Installation Manual
bandg.com
ENGLISH
VHF RADIO
User Guide
www.bandg.com | www.simrad-yachting.com | www.lowrance.com
12

Simrad RS40 Specifications

General

Type	VHF Marine Radio
Display	LCD
AIS Receiver	Yes
NMEA 2000	Yes
Waterproof Rating	IPX7
Output Power	25W
NMEA 0183	Yes
Modulation	FM
Power Supply	12V DC
DSC	Class D
Channels	International, US, Canadian
GPS	Built-in
Frequency Range	156.025 MHz to 162.025 MHz
Weight	1.2 kg
