4.3.6.3 System instance
For large boats, this function allocates a number to the radio
on a network when there is more than one network.
From the SimNet menu press O
K to enter the submenus and
use the
▲ and ▼ keys to select “SYSTEM INS”. Press OK to
enter the editing mode (the default number is “00”), then use
the
▲ and ▼ keys to allocate a network number (Fig 4.10) and
press O
K
to confirm. The radio will show “SELECT XX”
(where “XX” is the chosen number) for 2 seconds.
4.3.7 Serial number
The radio’s serial number can be found under the VHF Items
menu. From within the VHF Items menu press O
K and use the
▲ and ▼ keys to select “SERIAL NO”, which will display the
number for 2 seconds.
Press O
N/C to return to the upper menu level, or use the ▲ and
▼ keys to select another option.
Instruction manual
35
E04572
16
NO. 02
B
INT
Fig 4.10 - Allocating a number to a device where
there are several networks
▼▲
