Instruction manual
51
E04572
NOTE However, lifting the master handset will override all other sta-
tions, even if it is displaying “OCCUPIED”. All other stations
will be automatically locked out and display “OCCUPIED”
instead.
7.10 Adjusting backlighting
Both the LCD display and keypad are backlit – to enter back-
lighting mode press S
HIFT followed by CALL (DIMMER), then
use the V
OL ▲ and VOL ▼ keys to adjust the backlighting level
from “OFF” through level 1 (bright) to 5.
Press O
K or ON/C to exit the backlighting mode.
NOTE Backlighting levels are set individually and will only affect the
individual station.
7.11 Handset off cradle
When a handset is lifted off its cradle, all other stations will
display “OCCUPIED” (Fig 7.9). This means that these stations
are locked out until the handset is returned to the cradle,
unless it is an intercom call (see section 11.5).
STAT I ONAA2
OCCUP I EDBB
INT
16
Fig 7.9 - Station 2 handset is in use
