4.0 Mode 1, Display Description.
Mode 1 screen.
Printer Menu
Denotes: Printer Menu has been selected.
1
Shows the number of the selected mode. Press the MODE key to step through the
modes.
OnOff (F1).
Used to switch the printer option on or off.
Baud (F2).
Selects the communication speed (300 or 4800) between the instrument and serial
printer. The factory default setting is 300 baud.
Output (F3).
With the printer switched on, this feature allows a unique batch number to be printed
each time a measurement is taken. Once set, the number increments by 1 for each
subsequent test.
