Sindoh 3DWOX 7X - Page 136

Maintenance
5-24
5
2 Match one end of a new pad as shown in the following figure, and push it in the arrowed direction.
3 After inserting the pad, check that the pad is held by the hooks in three directions, as shown in the following
figure.
Caution
- When replacing pads, be careful not to damage or deform adjacent parts.
